SCXI-1302 NI

Description

SCXI-1302 NI

SCXI-1302 NI是National Instruments（NI）生产的一款模块化测量系统中的端子模块。其主要作用在于连接和接线测量信号，以便进行数据采集、测试和控制。这款模块能够将传感器、信号源和其他设备的信号引线方便地连接到模块化测量系统中。

规格：

• 信号连接端口：提供多个端口，用于连接测量信号、电压、电流等。
• 多路复用器功能：支持多个输入信号通过单个采集通道进行切换和采集。
• 接线方式：设计成易于用户接线的形式，简化信号连接和配置过程。
• 适配器和连接器：确保信号连接的稳定性和可靠性。
• 采样速率：支持高达1ms/s的采样速率。
• 分辨率：达到16位。
• 接口类型：支持USB、以太网、GPIB等多种接口。

作用特征：

• 高度模块化：作为NI模块化测量系统的一部分，可以与其他模块无缝集成，构建灵活的测量解决方案。
• 信号管理：提供高效的信号连接和路由功能，确保数据采集的准确性和实时性。
• 稳定性和可靠性：通过适配器和连接器的使用，确保信号连接的稳定性，减少信号干扰和失真。

应用领域：

• 实验室测试：用于科学研究和实验环境中的信号测量和数据采集。
• 数据采集系统：作为数据采集系统的重要组成部分，支持实时数据采集和监测。
• 传感器测量：与传感器配合使用，实现信号的采集、转换和传输。
• 自动化控制：在自动化系统中，用于信号监测和控制回路的构建。

The SCXI-1302 NI is a terminal block module from National Instruments (NI) designed for modular measurement systems. Its primary function is to connect and wire measurement signals for data acquisition, testing, and control. This module allows for the convenient connection of signal leads from sensors, signal sources, and other devices to the modular measurement system.

Specifications:

• Signal Connection Ports: Features multiple ports for connecting measurement signals, voltages, currents, and more.
• Multiplexer Functionality: Supports the switching and acquisition of multiple input signals through a single acquisition channel.
• Wiring Convenience: Designed with user-friendly wiring features to simplify signal connection and configuration processes.
• Adapters and Connectors: Ensures stability and reliability of signal connections.
• Sampling Rate: Supports a sampling rate of up to 1ms/s.
• Resolution: Achieves 16-bit resolution.
• Interface Types: Supports various interfaces such as USB, Ethernet, and GPIB.

Functional Characteristics:

• High Modularity: As part of the NI modular measurement system, it seamlessly integrates with other modules to create flexible measurement solutions.
• Signal Management: Provides efficient signal connection and routing capabilities, ensuring accurate and real-time data acquisition.
• Stability and Reliability: Ensures stable signal connections through the use of adapters and connectors, reducing signal interference and distortion.

Application Areas:

• Laboratory Testing: Used for signal measurement and data acquisition in scientific research and experimental environments.
• Data Acquisition Systems: Serves as a crucial component in data acquisition systems, supporting real-time data collection and monitoring.
• Sensor Measurements: Works hand-in-hand with sensors for signal acquisition, conversion, and transmission.
• Automation Control: Utilized in automation systems for signal monitoring and the construction of control loops.
