SCXI-1600 NI

Description

SCXI-1600 NI

NI SCXI-1600是一款高性能的数据采集和控制块，专为创建真正即插即用的USB数据采集系统而设计。它可与SCXI机箱中的其他SCXI模块组合使用，以构建测量和自动化系统的信号调理和开关平台。

规格：

• 总线类型：SCXI
• 操作系统：Windows, 实时系统, Linux
• 测量类型：电流, Temperature, 热电偶, 电压
• 通道数：32
• 采样率：166 kS/s
• 带宽：10 kHz
• 输入阻抗：1 GOhm
• 最大电压范围：-10..10 V
• 最大电流范围：0..20 mA

作用特征：

• 虚拟输入量：SCXI-1600共有32个可独立编程的虚拟输入量，可以对来自键盘和通讯协议的输入信号作出响应。
• 灵活配置：虚拟输入量的状态由控制电源进行保持，并可设为“取消”或“启用”，以实现灵活的逻辑操作。
• 高兼容性：兼容USB，支持供电或热插入USB端口，方便与外部设备连接。
• 高性能：具有高性能的信号调理功能，适用于各种传感器和原始信号的测量。

应用领域：

• 实验室测试与测量：用于科研和工程测试中的信号采集与测量。
• 工业自动化：在工业自动化过程中，实现数据的实时采集和控制。
• 环境监测：用于环境监测系统，对温度、湿度等环境参数进行实时监测。

The NI SCXI-1600 is a high-performance data acquisition and control block designed specifically for creating truly plug-and-play USB data acquisition systems. It can be used in combination with other SCXI modules within an SCXI chassis to construct a signal conditioning and switching platform for measurement and automation systems.

Specifications:

• Bus Type: SCXI
• Operating Systems: Windows, Real-time Systems, Linux
• Measurement Types: Current, Temperature, Thermocouple, Voltage
• Number of Channels: 32
• Sampling Rate: 166 kS/s
• Bandwidth: 10 kHz
• Input Impedance: 1 GOhm
• Maximum Voltage Range: -10..10 V
• Maximum Current Range: 0..20 mA

Functional Characteristics:

• Virtual Input Quantities: The SCXI-1600 features 32 independently programmable virtual input quantities that can respond to input signals from keyboards and communication protocols.
• Flexible Configuration: The state of the virtual input quantities is maintained by the control power supply and can be set to “cancel” or “enable” for flexible logic operations.
• High Compatibility: Compatible with USB, supports powered or hot-swappable USB ports for convenient connection with external devices.
• High Performance: Offers high-performance signal conditioning capabilities suitable for measuring various sensors and raw signals.

Application Areas:

• Laboratory Testing and Measurement: Used in scientific research and engineering testing for signal acquisition and measurement.
• Industrial Automation: Enables real-time data acquisition and control in industrial automation processes.
• Environmental Monitoring: Used in environmental monitoring systems for real-time monitoring of environmental parameters such as temperature and humidity.
