GE IS215ACLEH1A

Description

GE IS215ACLEH1A

GE IS215ACLEH1A是通用电气（GE）生产的一款电路板，属于EX2100系列的控制层模块。它是一款基于微处理器的控制器，设计用于工业自动化和控制系统。该电路板集成了多种功能，能够支持多种工业设备的运行和控制。

规格：

• 处理器类型：80386EX，速度为25MHz
• 工作环境温度：0至60摄氏度（32至140华氏度）
• 典型扫描速率：0.22毫秒/K
• 最大用户程序内存：32K字节
• 串行端口：支持SNP/SNP-X从机协议
• LAN端口：支持多点、以太网、FIP、Profibus、GBC、GCM和GCM+选项模块
• 电源需求：+5 VDC，670毫安



作用特征：

• 三重化设计：主处理器和I/O卡件完全三重化，避免因单点故障而引起系统停车。
• 高度集成：I/O卡件上的光隔离全部三重化，所有模拟卡件（AI, AO, PI）度高，并可以定期自动校验。
• 系统认证：经过TUV AK6级认证，满足SIL 3等级要求。
• 快速运行：32位芯片保证了系统的快速运行。
• 高诊断覆盖率：高度的系统诊断覆盖率，诊断功能皆为系统内置，不需编写应用程序。

应用领域：

GE IS215ACLEH1A电路板广泛应用于工业自动化和控制系统领域，特别是在需要高精度、高可靠性和快速响应的应用中。它可以用于各种工业设备的控制，如电机、驱动器、传感器等。此外，由于其高度的集成性和灵活性，它也可以用于各种定制化的控制系统解决方案中。

GE IS215ACLEH1A is a single-slot CPU module that belongs to the EX2100 series of General Electric Industrial Systems. This module is equipped with a CPU baseboard and seven expansion/remote baseboards. It uses the 80386EX processor type, running at a speed of 25MHz, and operates within a temperature range of 0 to 60°C (32 to 140°F). The module boasts a typical scan rate of .22 milliseconds per K and a maximum user program memory of 32K bytes. It features a built-in serial port supporting the SNP/SNP-X slave protocol and a LAN port supporting various options such as multipoint, Ethernet, FIP, Profibus, GBC, GCM, and GCM+. The controller supports shift registers, override, battery backup clock, PCM/CCM compatibility, periodic subroutine interrupt functionality, floating-point mathematics, and RAM and flash storage. It requires a +5 VDC power supply, providing 670 mA of current¹.

Specifications:

• Processor Type: 80386EX
• Processor Speed: 25MHz
• Operating Temperature: 0 to 60°C (32 to 140°F)
• Scan Rate: .22 milliseconds per K
• Maximum User Program Memory: 32K bytes
• Communication Interfaces: Serial Port (SNP/SNP-X), LAN Port (supporting multipoint, Ethernet, FIP, Profibus, GBC, GCM, and GCM+)
• Power Supply: +5 VDC, 670 mA

Functional Features:

• Triple redundancy in the main processor and I/O cards
• System stability due to the elimination of single-point failures
• Full triple redundancy in the optical isolation of I/O cards
• High-quality analog cards (AI, AO, PI) with regular automatic calibration
• System certified by TUV AK6 level, meeting SIL 3 requirements
• 32-bit chip ensuring rapid system operation
• High system diagnostic coverage with built-in diagnostic functions

Application Fields:

GE IS215ACLEH1A is primarily used as a microprocessor-based controller in industrial automation systems. It is part of the EX2100 series of control layer modules produced by General Electric Industrial Systems. The module is designed to be installed in innovative series drives or EX2100 control racks. It finds applications in various fields such as process control, motor control, and automation systems where high reliability, stability, and performance are crucial. The module’s advanced features and capabilities make it suitable for demanding industrial environments
