GE IC693PWR322F

Description

GE IC693PWR322F

GE IC693PWR322F 是一款综合了标准电源与模拟量扩展功能的模块。该模块不仅提供稳定的电源输出，还具备模拟量信号的监测与控制能力，适用于工业自动化和控制系统。

规格：

• 输入电源电压：24至48VDC
• 输出功率：30瓦
• 输出路数：三路，包括+5VDC、+24VDC隔离和+24VDC继电器输出
• 通信端口：RS485通信端口，9针子D连接器
• 保持时间：14ms
• 浪涌电流峰值：100安培，在最大4毫秒时
• 输入功率要求：最大50瓦（满负载使用期间）

作用特征：

• 电源输出稳定：提供多路稳定的电源输出，确保其他模块的稳定运行。
• 模拟量扩展：用于监测和控制各种工业过程中的模拟量信号，如温度、压力、流量等。
• 通信功能：通过RS485通信端口，可连接编程工作站和其他与RS485通信标准兼容的设备。
• 高可靠性：具备过压保护、过流保护等安全措施，确保模块的稳定运行。

应用领域：

• 工业自动化：用于工业自动化生产线，提供电源和模拟量信号的监测与控制。
• 控制系统：在控制系统中作为电源供应和信号采集模块，确保系统的稳定运行和数据的准确采集

The GE IC693PWR322F is a module that combines standard power supply and analog extension capabilities. It not only provides stable power output but also possesses the ability to monitor and control analog signals, making it suitable for industrial automation and control systems.

Specifications:

• Input Power Supply Voltage: 24 to 48VDC
• Output Power: 30 watts
• Number of Output Routes: Three routes, including +5VDC, +24VDC isolated, and +24VDC relay output
• Communication Port: RS485 communication port with a 9-pin sub-D connector
• Holding Time: 14ms
• Peak Surge Current: 100 amperes, at a maximum of 4 milliseconds
• Input Power Requirement: Maximum of 50 watts during full load operation

Functional Characteristics:

• Stable Power Output: Provides multiple stable power outputs to ensure the stable operation of other modules.
• Analog Extension: Used for monitoring and controlling analog signals in various industrial processes, such as temperature, pressure, and flow rate.
• Communication Capability: Connects to programming workstations and other devices compatible with the RS485 communication standard through the RS485 communication port.
• High Reliability: Equipped with safety measures such as overvoltage protection and overcurrent protection to ensure stable module operation.

Application Fields:

• Industrial Automation: Used in industrial automation production lines for power supply and analog signal monitoring and control.
• Control Systems: Serves as a power supply and signal acquisition module in control systems, ensuring stable system operation and accurate data acquisition.
