DS3820PSCB1C1B GE
DS3820PSCB1C1B GE是一款高性能、可靠的电源解决方案，适用于各种需要5V、+15V和-15V电压的应用。它能够将交流电转换为直流电，为负载提供所需的电压和电流。
规格：
- 输入电压：90-132VAC或180-264VAC
- 输入频率：47-63Hz
- 输出电压：+5V 20A, +15V 2A, -15V 2A
- 输出功率：120W
- 效率：>80%
- 纹波和噪声：+5V:<2mVrms, +15V:<1mVrms, -15V:<1mVrms
- 保护功能：过压保护、过流保护、短路保护、过温保护
- 尺寸：216mm x 102mm x 41mm（长x宽x高）
- 重量：1.2kg
- 工作温度：0°C至50°C
- 存储温度：-40°C至70°C
- 湿度：20%至80%（非冷凝）
作用特征：
- 宽输入电压范围，适应不同电源环境。
- 高效率，低纹波和噪声，确保供电质量。
- 多种保护功能，保障电源供应的安全性和稳定性。
- 符合多种安全标准，如UL、CSA和CE。
应用领域：
- 工业控制
- 通信设备
- 医疗设备
- 测试和测量设备
- 其他需要可靠电源的应用
DS3820PSCB1C1B GE is a high-performance and reliable power supply solution suitable for various applications requiring 5V, +15V, and -15V voltages. It converts AC power into DC power to provide the required voltage and current for the load.
Specifications：
- Input Voltage: 90-132VAC or 180-264VAC
- Input Frequency: 47-63Hz
- Output Voltage: +5V 20A, +15V 2A, -15V 2A
- Output Power: 120W
- Efficiency: >80%
- Ripple and Noise: +5V:<2mVrms, +15V:<1mVrms, -15V:<1mVrms
- Protection Features: Overvoltage Protection, Overcurrent Protection, Short-circuit Protection, Over-temperature Protection
- Dimensions: 216mm x 102mm x 41mm (L x W x H)
- Weight: 1.2kg
- Operating Temperature: 0°C to 50°C
- Storage Temperature: -40°C to 70°C
- Humidity: 20% to 80% (non-condensing)
Functional Characteristics：
- Wide input voltage range to adapt to different power environments.
- High efficiency, low ripple and noise to ensure power supply quality.
- Multiple protection functions to ensure the safety and stability of power supply.
- Compliant with multiple safety standards such as UL, CSA, and CE.
Application Fields：
- Industrial Control
- Communication Equipment
- Medical Equipment
- Test and Measurement Equipment
- Other Applications Requiring Reliable Power Supply
