1746-OW16 A-B

Description

1746-OW16 A-B

1746-OW16 A-B是一款由艾伦-布拉德利（A-B）公司制造的继电器输出模块，属于其SLC 500产品系列。该模块主要用于工业自动化控制系统中，通过控制外部设备实现逻辑控制功能。

规格：

• 通道数量：具有16个继电器输出通道。
• 控制电压：具有特定的控制电压，用于触发继电器的开关状态。
• 输出能力：每个继电器通道具有一定的电流和电压规格，以满足所连接外部设备的要求。
• 工作电压：5 – 125V DC 和 5 – 265V DC。
• 信号延迟：在最大阻性负载下，开和关状态均有10 ms信号延迟。

作用特征：

• 适用于混合电压类别的应用，如DC和AC电压。
• 具有两个输入组，每组一个公共端子，允许不同电压类型的工作。
• 消除了实现插入电路的需要，简化了控制系统设计。
• 易于使用，可通过计算机进行设置。
• 配备可移动的端子板，方便电缆或跳线的连接。

应用领域：

• 工业自动化系统中的控制设备、执行操作以及逻辑控制等。
• 机械设备控制、生产线自动化等场景。

The 1746-OW16 A-B is a relay output module manufactured by Allen-Bradley (A-B) as part of its SLC 500 product series. This module is primarily used in industrial automation control systems to achieve logic control functions through the control of external devices.

Specifications:

• Number of Channels: Features 16 relay output channels.
• Control Voltage: Has a specific control voltage for triggering the switching state of the relays.
• Output Capability: Each relay channel has certain current and voltage specifications to meet the requirements of the connected external devices.
• Operating Voltage: Ranges from 5 – 125V DC and 5 – 265V DC.
• Signal Delay: Has a signal delay of 10 ms in both on and off states under maximum resistive load.

Functional Characteristics:

• Suitable for mixed voltage applications, such as DC and AC voltages.
• Has two input groups, with one common terminal per group, allowing for different voltage types to operate.
• Eliminates the need for insertion circuits, simplifying control system design.
• Easy to use and can be set up through a computer.
• Equipped with a removable terminal block for convenient connection of cables or jumpers.

Application Areas:

• Control equipment, operational execution, and logic control in industrial automation systems.
• Scenarios such as mechanical equipment control and production line automation.
