DSAB-01C ABB

Description

DSAB-01C ABB

DSAB-01C是ABB生产的一款数字量输入模块。该模块具有多个数字量输入通道，能够接收开关状态、传感器信号或其他数字输入信号，并将它们转换为相应的电信号，以供控制系统进行处理和分析。DSAB-01C还具备高速采样率，能够快速捕获输入信号的变化，并提供信号隔离和防护功能，以确保安全和可靠的信号采集。

规格：

• 输入通道数量：多个
• 信号类型：开关量输入、脉冲输入、频率输入等
• 采样率：高速
• 防护等级：IP20
• 工作温度范围：-25°C至+55°C
• 尺寸：45 x 99 x 114 mm
• 重量：0.20 kg



作用特征：

• 多通道输入：支持多个数字量输入通道，实现多信号同时采集。
• 信号转换：将接收到的数字输入信号转换为电信号，供控制系统处理。
• 高速采样：快速捕获输入信号的变化，确保实时性。
• 信号隔离与防护：提供信号隔离和防护功能，增强系统的安全性和可靠性。
• 通信接口：支持常见的数据通信接口，如以太网、串口等，方便与其他设备或系统进行数据交换和通信。
• 配置与监测：支持配置和监测功能，便于通道的设置和监控。

应用领域：
DSAB-01C广泛应用于电力电子和逆变器应用，如UPS（不间断电源）系统、变频器和电力调整设备。同时，它也被用于工业逆变器，控制和调整工业电机、驱动器和其他设备的电力供应。在可再生能源系统中，DSAB-01C被用于风力发电和太阳能逆变器，将可再生能源产生的直流电转换为交流电

The DSAB-01C is a digital input module produced by ABB. This module features multiple digital input channels, capable of receiving switch status, sensor signals, or other digital input signals. It converts these signals into corresponding electrical signals for processing and analysis by the control system. The DSAB-01C boasts a high-speed sampling rate, quickly capturing changes in input signals, and offers signal isolation and protection for safe and reliable signal acquisition.

Specifications:

• Number of Input Channels: Multiple
• Signal Types: Switch input, pulse input, frequency input, etc.
• Sampling Rate: High-speed
• Protection Class: IP20
• Operating Temperature Range: -25°C to +55°C
• Dimensions: 45 x 99 x 114 mm
• Weight: 0.20 kg

Functional Features:

• Multi-channel Input: Supports multiple digital input channels for simultaneous signal acquisition.
• Signal Conversion: Converts received digital input signals into electrical signals for processing by the control system.
• High-speed Sampling: Quickly captures changes in input signals for real-time performance.
• Signal Isolation and Protection: Provides signal isolation and protection for enhanced system safety and reliability.
• Communication Interfaces: Supports common data communication interfaces such as Ethernet, serial ports, etc., facilitating data exchange and communication with other devices or systems.
• Configuration and Monitoring: Supports configuration and monitoring features for easy channel setup and monitoring.

Application Fields:
The DSAB-01C finds widespread applications in power electronics and inverter applications, such as UPS (Uninterruptible Power Supply) systems, frequency converters, and power adjustment equipment. Additionally, it is used in industrial inverters for controlling and adjusting the power supply to industrial motors, drives, and other devices. In renewable energy systems, the DSAB-01C is employed in wind and solar inverters, converting direct current (DC) generated by renewable sources into alternating current (AC).
