3BDH000320R0101 ABB

Description

3BDH000320R0101 ABB

3BDH000320R0101是ABB公司生产的一款先进的高速以太网模块，名为LD800HSE。它被广泛应用于工业自动化和技术解决方案领域，为工业网络提供高效、可靠的通信支持。

规格：

• 电源电压：24 V DC（±20%）
• 尺寸：47 x 131 x 111毫米
• 安装方式：安装在35mm的DIN导轨上
• 重量：约0.4kg
• 防护等级：IP 20
• 信号传输能力：对于800xA SV5.1以后的系统，HSE和H1之间的信号传输能够在所有四个H1链路和HSE网络之间每秒最多处理160个信号，而4*16客户端/服务器连接可以并行使用¹



作用特征：

• 以太网/IP协议兼容性：与广泛使用的以太网/IP协议兼容，允许与支持该协议的其他设备和系统无缝集成。
• 诊断与监控功能：提供实时状态信息和性能数据，支持主动维护和故障排除，有助于减少停机时间并优化网络性能。
• 用户友好：设计便于安装和配置，具有用户友好的界面，支持多种配置选项，可以无缝集成到现有的工业网络中。
• 安全功能：配备强大的安全功能，防止未经授权的访问，确保数据完整性。

应用领域：

3BDH000320R0101适用于各种复杂的工业环境，无论是需要连接单个工厂内的设备还是跨多个位置的设备，它都能提供稳定且高效的连接和性能。广泛应用于制造业、化学处理、水处理、食品饮料加工等多个领域

The 3BDH000320R0101 is an advanced high-speed Ethernet module produced by ABB, named LD800HSE. It is widely used in industrial automation and technical solution fields, providing efficient and reliable communication support for industrial networks.

Specifications:

• Power Supply Voltage: 24 V DC (±20%)
• Dimensions: 47 x 131 x 111 mm
• Installation Method: Mounted on a 35 mm DIN rail
• Weight: Approximately 0.4 kg
• Protection Level: IP 20
• Signal Transmission Capability: For systems after 800xA SV5.1, the signal transmission between HSE and H1 can handle up to 160 signals per second between all four H1 links and the HSE network, while 4*16 client/server connections can be used in parallel¹

Features:

• Ethernet/IP Protocol Compatibility: Compatible with the widely used Ethernet/IP protocol, allowing seamless integration with other devices and systems that support this protocol.
• Diagnostic and Monitoring Functions: Provides real-time status information and performance data, supporting proactive maintenance and troubleshooting, which helps to minimize downtime and optimize network performance.
• User-Friendly: Designed for ease of installation and configuration, with a user-friendly interface supporting various configuration options, allowing seamless integration into existing industrial networks.
• Security Features: Equipped with robust security features to prevent unauthorized access, ensuring data integrity.

Application Fields:

The 3BDH000320R0101 is suitable for various complex industrial environments. Whether it is connecting devices within a single factory or across multiple locations, it can provide stable and efficient connectivity and performance. It is widely used in manufacturing, chemical processing, water treatment, food and beverage processing, and many other fields
